مشخصات فنی:

Mutual Capacitance: 5.6nF/100m nominal Characteristic Impedance: 100Ω±15%,1-600MHz Nominal Velocity of Propagation: 69% (Operating Temperature: -20℃-60℃(-4℉-140℉ (Storage Temperature: -20℃-80℃(-4℉-176℉ مشخصات کابل : Conductor: 24 AWG(7/0.203 ±0.007mm), Multi-cores ( 7 cores at the least) Conductor Metal: Bare Copper Insulation Material: HD-PE OD: 1.10 ±0.05mm Average Thickness: 0.25 mm Outside-Tape Metal: MYLAR Overlap Rate: 25% (Drain Wire: 26 AWG(7/0.160 ±0.007mm (Jacket hardness: 45P (90A ± 2A, Shore Material: PVC UL94V-0 OD: 7.0mm ±0.2 Average Thickness: 0.60 mm Color: Cool Gray 5C Length type: 3000mm ± 30mm کاربرد : (10BASE-T, 100BASE-TX Fast Ethernet, 1000BASE-T, 10GBASE-T (IEEE802.3 100VG-AnyLAN (IEEE802.12) 550 MHz Broadband Video Voice, T1, ISDN 155/ 622 Mbps ATM (Power over Ethernet (POE

AWG (ضخامت کابل):

24AWG

طبقه‌بندی:

Cat 6
